    Fully Automatic Hot Sell Concrete Reinforcing Steel Welded Wire Mesh Machine From China

    Ask Lasest Price
    Brand Name : MLG
    Model Number : WHJ-2500
    Certification : CE
    Supply Ability : 4--5 sets per month
    Delivery Time : 30 days after receiving deposit or L/C.
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    Fully Automatic Hot Sell Concrete Reinforcing Steel Welded Wire Mesh Machine From China

    Fully Automatic Hot Sell Concrete Reinforcing Steel Welded Wire Mesh Machine From China


    Main features:


    1.The control system adopts synchronous CNC technology, Panasonic PLC program and HMI. It is easy and convenient to operate with the touching screen.


    2. The fallen wire system sends weft wires one by one automatically instead of putting wefts wires by manual work, increasing productivity.


    3. The sending mesh system controlled by computer can make—Adjustable distance of line wire that allows different opening size between the line wire, when input the distance of cross wire to computer, any character can be reach. Welding aperture can adjust randomly within range.


    4. The main engine adopts imported and famous pneumatic components, making the service life long.


    5. The welding wire is accurate and the welding points are firm for the big pressure.


    6. This machine equips typical and efficient transformer, which gearless adjusted, enlarging the welding range.


    Main parameter:


    Wire diameter5--12mmLine wire formpre-cut wire
    Weft wire distance

    100mm--300mm

    (adjustable)

    Weft wire formpre-cut wire
    Line wire distance

    100mm--300mm

    (adjustable)

    Rated voltage380V/50HZ 3 phase
    Mesh width2500mmWater cooling Transformer power125KVA X 13
    Welding speed40-- 50times/minOverall dimension20X 3.4X 2.4M
    Welding spot heads.26Max. mesh length6m
    Total weight7.5TMotor11KW
